Dot matrix font

5×5,7×6,7×8,8×12,12×12,16×16,24×24

Printing lines

1-4 lines

Character height

1-15MM

Printing speed(7x5)

3 m/s

Printing length

1024 characters

Printing ink

Black,blue,red etc. dye based ink

Input mode

Keyboard operation

Operation interface in both English and Chinese
pin yin input method
location input method

Printing direction

Normal words,opposite words,reversed words, opposite reversed words, can set print direction for a single character

Font wider

1 ~ 9 times, can widen the font for a single character

Font Spacing

1-8 times,can edit point by point at will

Stored Info

Unlimited

Printing content

Dates,times,automatic date,automatic validity period,lot number ,numbers,four groups counts,variable bar code,anti-counterfeiting code,two-dimension code,multi language,multi fonts(Support for individual signature )

Communication function

SD cards   USB drives  RS232 serial inputs

Other communication function

Encoder input       photoelectric switch input       alarm Signal Output reservation multiple output control

Power

50W

Power Supply

110/220 VAC, 50/60 Hz

Ambient temperature

-10°C ~45°C

Ambient humidity

10~95% non condensing

Contour size

400x290x515mm

Nozzle tube

3 meters

Shell and weight

304 stainless steel,IP55,27kg
